RALLY S. LOEB - DACIA SANDRIDERS TEAM
communication system
SYSTEM DIAGRAM OF THE TYPICAL ZN RALLY ARCHITECTURE FOR ILLUSTRATIVE PURPOSES ONLY
The Rally Systems enable communication between driver and co-driver with extensive Power and Noise Cancelling.
They also feature radio, Bluetooth, and Car camera connection.
COMPONENTS
Amplifiers
Extensions and adaptors (if needed for different connector systems, Helmet radio kits
e.g. components produced by other manufacturers) Headsets
DRIVER CO-DRIVER
HELMET/HEADSET HELMET/HEADSET
Female 4 pin nexus connector Female 4 pin nexus connector
on helmet or headset on helmet or headset
Male 4 pin nexus Male 4 pin nexus
connector on amplifier connector on amplifier
AMPLIFIER
