ADAPTORS
COMPATIBILITY TABLE communication
DEVICES

YOUR AMPLIFIER, INTERCOM, YOUR HELMET, HEADSET OR RADIO HELMET KIT CONNECTOR
RADIO OR PHONE CONNECTOR
STANDARD (EU) IMSA (USA)
MALE NEXUS 4 PIN FEMALE NEXUS 4 PIN MALE NEXUS 5 PIN MALE NEXUS 4 PIN

MALE NEXUS 4 PIN
6400005 EXTENSION 6400006 MADE TO ORDER 6400008
STANDARD (EU) FEMALE NEXUS 4 PIN EXTENSION 6400006 6400004 MADE TO ORDER 6400009

FEMALE NEXUS 5 PIN
6400012 6400013 MADE TO ORDER MADE TO ORDER

FEMALE NEXUS 4 PIN
6400009 6400007 MADE TO ORDER MADE TO ORDER
IMSA (USA) FEMALE NEXUS 5 PIN
C
M NA NA NA 6400014
Y FEARLESS WIRELESS AMPLIFIER
PHONE CONN. 3.5 mm
CM
6400010 6400011 MADE TO ORDER MADE TO ORDER
MY
CY
CMY
K
ADAPTORS some adaptors example
STANDARD (EU)
REFERENCE ADAPTOR TYPE CONNECTOR 1 CONNECTOR 2 CABLE TYPE LENGHT
6400004 ADAPTOR MALE NEXUS 4 PIN MALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400005 ADAPTOR FEMALE NEXUS 4 PIN FEMALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400006 EXTENSION MALE NEXUS 4 PIN FEMALE NEXUS 4 PIN COILED CABLE 150 cm
6400012 ADAPTOR FEMALE NEXUS 4 PIN MALE NEXUS 5 PIN STRAIGHT CABLE 15 cm
6400013 ADAPTOR MALE NEXUS 4 PIN MALE NEXUS 5 PIN STRAIGHT CABLE 15 cm
6400021 ADAPTOR EXTENSION FEMALE NEXUS 4 PIN / RCA MALE NEXUS 4 PIN COILED CABLE 150 cm
6400022 ADAPTOR MALE NEXUS 4 PIN / RCA MALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400023 ADAPTOR FEMALE NEXUS 4 PIN / RCA FEMALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
IMSA (USA)
REFERENCE ADAPTOR TYPE CONNECTOR 1 CONNECTOR 2 CABLE TYPE LENGHT
6400008 ADAPTOR FEMALE NEXUS (IMSA) 4 PIN FEMALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400009 ADAPTOR MALE NEXUS (IMSA) 4 PIN FEMALE NEXUS 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400007 ADAPTOR MALE NEXUS 4 PIN MALE NEXUS (IMSA) 4 PIN COILED CABLE CROSSED WIRING 15 cm
6400014 ADAPTOR FEMALE NEXUS (IMSA) 4 PIN MALE NEXUS (IMSA) 5 PIN STRAIGHT CABLE 15 cm
STANDART SMARTPHONE
REFERENCE ADAPTOR TYPE CONNECTOR 1 CONNECTOR 2 CABLE TYPE LENGHT
6400010 ADAPTOR MALE NEXUS 4 PIN JACK 3.5mm SMARTPHONE STRAIGHT CABLE 50 cm
6400011 ADAPTOR FEMALE NEXUS 4 PIN JACK 3.5mm SMARTPHONE STRAIGHT CABLE 50 cm
