STEERING WHEELS STEERING WHEELS

STEERING WHEELS ACCESSORIES STEERING WHEELS ACCESSORIES

QUICK RELEASE HUB TO BE WELDED STEERING WHEEL SPACERS

Quick release hub in aluminium with 6 holes. Compatible with 3 or 6 Steering wheel spacer in anodized Ergal EN AW 7075
holes steering wheel. Recommended use of PTFE dry lube to get the machined from solid. Specific grooves for wires and cables.
best performance and preserve all components. Compatible with all 6x70mm steering wheels. Available in
Also available with 11 pin professional electrical connectors included several heights:
(this part is an high performance interconnection engineered with arc-
shape metal guides, which ensure a rapid and precise alignment of the Color: dark grey
11 contacts. Aluminium body, IP68 sealing, 10000 cycles guarantee, 109mm
high temperature and chemical resistance).
Connector model:
FISCHER SFE 104 A056-130 (male)
FISCHER DEE 104 A056-130 (female)
TO BE WELDED WITH
TO BE WELDED CONNECTOR INCLUDED
OS0-0024-A03 OS0-0024-A04 CLOSED 73mm 20mm 40mm 60mm 80mm 100mm

OS0-0026-20 OS0-0026-40 OS0-0026-60 OS0-0026-80 OS0-0026-100

QUICK RELEASE HUB TO BE BOLTED

WHEEL PLATE FACE PROTECTION
Quick release hub in aluminium with 6 holes. Compatible with 3 or 6
holes steering wheel. Recommended use of PTFE dry lube to get the OD0-2029 OD0-2052-B01
best performance and preserve all components.
Also available with 11 pin professional electrical connectors included For use of up to Universal face protection
(this part is an high performance interconnection engineered with 2 buttons (included). for steering wheel. Suede
arc-shape metal guides, which ensure a rapid and precise alignment of 2 drill points for leather upholstering, it
the 11 contacts. Aluminium body, IP68 sealing, 10000 cycles guarantee, 109mm attachment between fits on any racing steering
high temperature and chemical resistance). steering wheel and hub. wheel thanks to the
Connector model: Fixing screws included. Example of mounted plate three adjustable velcro’s
FISCHER SFE-104-A056-130 (male) straps. Made in ultralight
FISCHER DEE-104-A056-130 (female) Carbon fiber. CONFOR™ foam CF45M
Thickness: 2.5 mm (blue) in compliace with
TO BE BOLTED WITH FIA Appendix J Article 285
TO BE BOLTED
CONNECTOR INCLUDED (revision August 2020).
OS0-0024-A01 OS0-0024-A02 CLOSED 39mm Depth:
40 mm, Diameter: 160 mm.

QUICK RELEASE HUB 72mm FIXED STEERING WHEEL SPACERS WHEEL PLATE

OS0-0023 OD0-2026
6 holes quick release hub in aluminium. With ‘butterfly’ shape to avoid
interaction with shift paddle. Compatible with 3 or 6 holes steering Depth: 60 mm Carbon fiber.
wheels. Alvailable in to be welded version (ODS/025/W) or in to be Thickness: 2.5 mm
bolted version (ODS/025/B).
Anodized silver For use of up to 4 buttons
TO BE BOLTED TO BE WELDED OS0-0023-081 (not included).
OS0-0025-A01 OS0-0025-A02 109mm 6 drill points for
Anodized black attachment.

OS0-0023-071 Fixing screws included.

AVAILABLE ON REQUEST WITH PROFESSIONAL
ELECTRICAL CONNECTOR STEERING WHEEL HUBS

TO BE BOLTED TO BE WELDED OD0-1960-... see the application list
OS0-0025-A03 OS0-0025-A04 ODS/025/B CLOSED 39mm on www.ompracing.com
and on QR code
ODS/025/W CLOSED 73mm These steering wheel hubs
have been designed so as
to maintain the original steering
wheel (flat model) position.
