P. 189
communication system
SYSTEM DIAGRAM OF THE TYPICAL ZN WIRED/WIRELESS ARCHITECTURE FOR ILLUSTRATIVE PURPOSES ONLY
The Wired-Wireless (WW) System enables communication between driver and co-driver both in Wired and Wireless mode. When the helmet IS
connected to the amplifier via cable, the communication works traditionally, also keeping compatibility with any Nexus communication system.
When the helmet IS NOT connected to the amplifier via cable, the system switches automatically to the wireless mode with no interruption whatsoever.
COMPONENTS
WW Zeronoise Amplifier
WW Bell Helmet radio kits / Helmet radio kits produced by other manufacturers Extensions and adaptors (if needed for different connector
WW Zeronoise Headsets / Headsets produced by other manufacturers systems, e.g. components produced by other manufacturers)
DRIVER CO-DRIVER
HELMET/HEADSET HELMET/HEADSET Foto??
Female 4 pin nexus connector Female 4 pin nexus connector
on helmet or headset on helmet or headset
Male 4 pin nexus connector on amplifier
Male 4 pin nexus
WIRELESS MODE WIRED MODE WW AMPLIFIER
connector on amplifier
MAX SMART - CAMERON FAIR / FIA RALLY STAR
- PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE USING -
