                                                                                                                                                                                                      communication
                                                                                                                                                                                                                 DEVICES

                            COMMUNICATION SYSTEM
                                                                                                                                                 COMMUNICATION SYSTEM
                                                          WIRED MODE
                                                                                                                                                                    wireless MODE
       The Wired-Wireless (WW) System enables communication between driver and co-driver both in Wired and Wireless mode.
       When the helmet IS connected to the amplifier via cable, the communication works  traditionally, also keeping compatibility with any Nexus   When the helmet IS NOT connected to the amplifier via cable, the system switches automatically to the wireless mode with no interruption
       communication system.                                                                                            whatsoever.


         COMPONENTS                                                                                                       COMPONENTS
        WW Zeronoise Amplifier                                                                                           WW Zeronoise Amplifier
        WW Bell Helmet radio kits / Helmet radio kits produced by other manufacturers  Extensions and adaptors (if needed for different connector  WW Bell Helmet radio kits
        WW Zeronoise Headsets / Headsets produced by other manufacturers  systems, e.g. components produced by other manufacturers)  WW Zeronoise Headsets


         system architecture                 Male 4 pin nexus connector on amplifier, female 4 pin nexus connector on helmet or headset.  system architecture  Wireless connection.



                     DRIVER                                             CO-DRIVER                                                    DRIVER
                HELMET/HEADSET                                         HELMET/HEADSET                                            HELMET/HEADSET






 C
 M
 Y
 CM
 MY
 CY
                                                                                                                                                           ww AMPLIFIER
 CMY
 K
                       Female 4 pin nexus connector                  Female 4 pin nexus connector
                       on helmet or headset                                on helmet or headset




                                                                                                                                                                                                              NEW
                                                                                                                                                                                                      SYSTEM


                      Extensions and adaptors                            Extensions and adaptors
                                                                                                                         THE WW SYSTEM MAINTAINS COMPATIBILITY WITH ANY NEXUS COMMUNICATION SYSTEM
                       Male 4 pin nexus                                       Male 4 pin nexus
                       connector on amplifier                              connector on amplifier




                                           ww AMPLIFIER







                          NEW
                   SYSTEM
