CEFAL4
EXTINGUISHERS

This fire extinguisher system is homologated FIA 8876-
CE0-FAL4-A01 2022, the last and innovative FIA standard for plumbed
OMP in-fire suppression system for open cockpit cars. The bottle
CEFAL4 is made in aluminum with an innovative save spacing
XXXXXXX
ON REQUEST 8876 - 2021 solution.The system covers a wide range of fuels (from
petrol till E85 CLASS I II and V (E85)) and it is suitable for
electric and hybrid cars also.The extinguishing medium LIGHTWEIGHT WATER PROOF ELETRIC
when released, is non-corrosive and not electrically ALUMINIUM SYSTEM
FORMULA conductive.In contrast to foam or powder, it does not leave
any damaging residues, so the systems do not have to be
cleaned and remain up and running after the release of the
fluid.The system gets pressurized when activated, enabling
the discharge of the extinguishant.The electrical system is
Ø 110 mm waterproof and ready to be installed and the ECU is IP65
and IP67 certified.Fixing brackets, clamps, piping, and
SUITABLE FOR ELECTRIC connections are included.
AND HYBRID CARS

Homologated for use on:
Petrol - class I
Petrol + up to 30% ethanol
or methanol (E30) - class II
Petrol + up to 85% ethanol
or methanol (E85) - class V

ONE COLLECTION FIA 8876-2022 - CEFAL4

Ref. Extinguishant Empty (kg) Total weight*
CEO-FAL4-AO1 2 kg Novec 1230 1.2 3.2 kg
TM

275

226
WIRING NOZZLES PUSH BUTTON STICKERS 90°
CONNECTIONS
4x 1x 2x 4 Ø 8
110

Y CONNECTIONS HOSE 8M AL TUBING Ø8 CONTROL BOX 3 WAY
CONNECTIONS MEASUREMENTS IN MM
1x 10m 1x 2 Ø 8
132 133
