SEATS SEATS
SPECIFIC BRACKETS FIA 8862-2009 UNIVERSAL BRACKETS

FIA 8855-2021

SIDE MOUNT
OMP can design, produce and homologate custom brackets upon request for any seat according to customer BRACKET
needs. Brackets can be developed for any FIA standard (Technical list. 40 and 91 and Art. 253). DIMENSIONS Lowest rear mounting hole“A” Lowest front mounting hole “D” Length of mounting plate “E”
The dimensions Width of mounting plate “F” Longitudinal range “G”
are in mm. Rear range “B” Front range “C” Type of bolt pattern Number of holes
STAFFA
HC0-0731-B01 110 34.5 93 70.5 B 350 45 75 4
HC0-0733-B01 109 17 94 70.5 A 350 52 25 3
SEAT BRACKETS FOR HTE ONE LITE RALLY SEAT BRACKETS FOR HTE ONE E HC0-0830 77 66 66 77 B 495 48.5 126 6
HC0-0830-B02 112 51 108 73.5 A 422.5 59 112.5 10
HC0-0934 FIA 8862-2009 HC0-0940 FIA 8862-2009 HC0-0922 85 81 81 85 B 400 52 75 4
HC0-0923 75,5 100 100 75,5 B 495 50 125 6
HC0-0924 85 81 81 85 B 400 52 75 4
HC0-0925 75,5 100 100 75,5 B 495 50 125 6
UPON REQUEST
STEEL BRACKET STEEL BRACKET
HC0-0922 FIA APPENDIX J ART. 253 HC0-0731-B01 FIA APPENDIX J ART. 253
Tall model. Steel. Tall model. Steel.
Length: 400 mm Length: 350 mm
SEAT BRACKETS SEAT BRACKETS FOR HTC ONE - HTE ONE 2 Thickness: 3 mm Thickness: 3 mm
Ultra strong material. Ultra strong material.
HC0-0880-A01 for HTE ONE HC0-0928 for HTE ONE XL HC0-0935-A01 for HTC ONE FIA 8862-2009
HC0-0880-A02 for HTE ONE S FIA 8862-2009 HC0-0935-A02 for HTE ONE E 2
FIA 8862-2009

STEEL BRACKET STEEL BRACKET

HC0-0733-B01 FIA APPENDIX J ART. 253 HC0-0923 FIA APPENDIX J ART. 253

Low model. Steel. Tall model. Steel.
Length: 350 mm Length: 495 mm
Thickness: 3 mm Thickness: 3 mm
Ultra strong material. Ultra strong material.
SEAT BRACKETS FIA 8862-2009 SEAT BRACKETS FIA 8855-2021

HC0-0907 for HRC ONE (AS.033.14) HC0-0945

HC0-0929-A01 for HRC ONE LITE (AS.075.19) for HTC-EVO CARBON (S.009.21) ALUMINIUM BRACKET ALUMINIUM BRACKET
HC0-0929-A02 for HRC ONE LITE RC (AS.083.19)
HC0-0924 FIA APPENDIX J ART. 253 HC0-0925 FIA APPENDIX J ART. 253

Tall model. Aluminium. Tall model. Aluminium.
Length: 400 mm Length: 495 mm
Thickness: 6 mm Thickness: 6 mm
Ultra strong material. Ultra strong material.

SEAT BRACKETS FIA 8855-2021

HC0-0951-A01 for HTE EVO 2 CARBON (CS.016.23) STEEL BRACKET
HC0-0951-A02 for HTE EVO (CS.017.23) HC0-0830 FIA APPENDIX J ART. 253
HC0-0951-A03 for HTC EVO (CS.015.23)
HC0-0951-A04 for HTE EVO 2 XL (CS.019.24) Tall model equipped with a damper. Aluminium.
HC0-0951-A05 for HTE EVO 2 S Patented model. Length: 495 mm Thickness: 6 mm
DAMPING ELEMENT
to reduce vertical loads on the driver.
Suitable for off-road.
72 73
